Acoustic Properties of Triglycine Sulphate Crystals with Alanine Impurity
Abstract
The frequency- and concentration-dependent absorption coefficients of longitudinal and transverse ultrasonic waves in pure and α-alanine-doped triglycine sulfate (α-TGS) crystals (α-alanine content in crystals is: 5, 10, 15, 20, 25, 30, and 35 mol%) grown from solution at room temperature were studied. It is established that absorption coefficients of ultrasonic waves in α-TGS crystals with L and S polarization with the increase in concentration of α-alanine about 1.57 and 1.88 times decrease, and propagation velocity increases by 3.24 and 13.38%, respectively. Decrease of absorption coefficients of transverse ultrasonic waves caused by elastic scattering of phonons on impurity, i.e., decrease of τ, at the corresponding dispersive properties of a phonon subsystem.
Downloads
References
M.E. Lines, and A.M. Glass, Principles and Applications of Ferroelectrics and Related Materials, (OUP Oxford, Science, 2001).
B.A. Strukov, and A.P. Levanyuk, Ferroelectric Phenomena in Crystals, (Springer, Geydelberg, 1998).
H. Toyada, Sh. Waku, and H. Hirabayshi, “Structure of Ferroelectric Domains in Triglycine Sulphate,” Journal of the Physical Society of Japan, 14(8), 1003-1011 (1959). https://doi.org/10.1143/jpsj.14.1003
M.B. Dung, and H.T. Nguyen, “Influence of Gamma Irradiation on Properties of Ferroelectric Composite from Cellulose Nanoparticles and Triglycine Sulfate,” Materials Transactions, 60(9), 1902-1907 (2019). https://doi.org/10.2320/matertrans.mt-m2019139
S. Goel, N. Sinha, A. Hussain, A.J. Joseph, H. Yadav, and B. Kumar, “Sunset yellow dyed triglycine sulfate single crystals: enhanced thermal, mechanical, optical and di-/piezo-/ferro-/pyro-electric properties,” Journal of Materials Science: Materials in Electronics, 29(16), 13449–13463 (2018). https://doi.org/10.1007/s10854-018-9470-9
B. Mytsyk, N. Demyanyshyn, A. Erba, V. Shut, S. Mozzharov, Y. Kost, O. Mys, and R. Vlokh, “Piezo-optic and elasto-optic properties of monoclinic triglycine sulfate crystals,” Journal of Applied Optics, 56(34), (2017). https://doi.org/10.1364/ao.56.009484
O. Krupych, M. Kostyrko, D. Adamenko, I. Skab, and R. Vlokh, “Tracing of optic axis with an acouto-optically diffracted beam: generation of vector-vortex beam in triglycine sulphate crystals,” J. Phys. Opt. 21, (2020). https://doi.org/.3116/16091833/21/1/1/2020
M.J. Ibrahim, and T.M. Ai-Saadi, “Investigating the Effect of Doping and Sulfuric Acid (H2SO4) on the Growth and Properties of a Triglycine Sulphate (TGS) Crystal,” IOP Conf. Ser.: Mater. Sci. Eng. 871, 012082 (2020). https://doi.org/10.1088/1757-899x/871/1/012082
R. Raja, V. Santhanam, D. Vedhavalli, and P.K. Nathan, “Investigation on mechanical, dielectric and thermal properties of aluminum doped TGS single crystal,” International Journal of Material Science, 12(2), 185-196 (2017). https://www. ripublication.com › ijomsv12n2spl_22
E. Theocharous, “Absolute linearity measurements on a gold-black-coated deuterated L-alanine-doped triglycine sulphate pyroelectric detector,” Applied Optics, 47(21), 3731-3736 (2008). https://doi.org/10.1364/ao.47.003731
V.Yu. Kurlyak, V.Yo. Stadyuk, B.V. Andriyevsky, M.O. Romanyuk, Z.O. Kohut, and V.M. Gaba, “Optical properties of D-serine doped TGS crystals for pyroelectric sensors,” Material Science-Poland, 33(4), 692-698 (2015). https://doi.org/10.1515/msp-2015-0105
R.B. Lal, and A.K. Batra, “Growth and properties of triglycine sulfate (TGS) crystals: Review,” Ferroelectrics, 142(1), 51-82 (1993). http://dx.doi.org/10.1080/00150199308237884
H.V. Alexandrru, “Pure and Doped Triglycine Sulfate Crystals Growth and Characterization,” Interdisciplinary Transport Phenomena: Ann: N. Y. Acad. Sci. 1161, 387-396 (2009). https://doi.org/10.1111/j.1749-6632.2008.04080.x
N.V. Belugina, R.V. Gainutdinov, A.L. Tolstkhina, V.V. Dolbinina, N.I. Sorokina, and O.A. Alekseeva, “Nanorelief of the Natural Cleavage Surface of Triglycine Sulphate Crystals with Substitutional and Interstitial Impurities,” Crystallography Reports, 56(6), 1070-1076 (2011). https://doi.org/10.1134/s1063774511030047
V.N. Shut, I.F. Kashevich, and S.R. Syrtsov, “Ferroelectric properties of triglycine sulfate crystals with non-uniform distribution of chromium impurity,” Physics of the Solid State, 50(16), 115-118 (2008). (in Russian)
V. Windsh, I. Rakhimov, V.M. Sarnatsky, E.V. Charnaya, and V.A. Shutylov, “Ultrasonic studies of the structural phase transition in impurity TGS crystals,” Physics of the Solid State, 27(6), 1671-1674 (1985). (in Russian)
A.L. Tolstikhina, N.V. Belugina, R.V. Gainutdinov, E.S. Ivanova, A.K. Lashkova, V.N. Shut, I.F. Kashevich, et al., “Domain structure and properties of triglycine sulfate crystals layer-by-layer doped with D, L-α- and L-α-alanine impurity,” Crystallography, 61(6). 975-981 (2016). https://doi.org/10.1134/s106377451606016x
T.Ch. Upadhyay, and A. Nautiyal, “Effect of Electric Field on Dielectric and Acoustic Properties of triglycine Sulphate Crystal,” AIP Conference Proceedings, 1372, 1 (2011). https://doi.org/10.1063/1.3644410
E.V. Charnaya, and I. Rakhimov, “Acoustic studies of imperfect TGS crystals,” Ferroelectrics, 112(1), 45-54 (1990). https://doi.org/10.1080/0015019900-8012784
E.V. Charnaya, A.A. Kuleshov, A.K. Radzhabov, I.K. Rakhimov, and L.A. Shuvalov, “Frequency-independent order parameter relaxation time in TGS crystals,” Ferroelectrics, 143(1), 143-148 (1993). https://doi.org/10.1080/001501-99308008323
S.N.Drozhdin, O.M. Golitsyna, A.I. Nikishina, F.A. Tuma, D.P. Tarasov, “Relaxation of the Domain Structure in Triglycine Sulphate and Deuterated Triglycine Sulfate Crystals in the Couse of Polarization Switching,” Physics of the Solid State, 48(3), 532-536 (2006). (in Russian)
A. Levanyuk, “On the phenomenological theory of sound absorption near the points of second-order phase transitions,” JETP, 49, 1304 (1985). (in Russian)
F.A. Salakhitdinov, E.V. Charnaya, and V.A. Shutilov, “Absorption of high-frequency ultrasound during phase transition in triglycine sulfatem” in: IV All-Russian Symp. on Physics of Acoustohydrodynamic Phenomena and Optoacoustics. (Ashgabat, 1985), pp. 69.
Yu.A. Logachev “Difference in absorption of longitudinal and transverse sound in impurity crystals,” Physics of the Solid State 15(11), 3454-3455 (1973). (in Russian)
